Jobsite Camera

Months of construction captured in minutes of time lapse video!

The Brinno Construction Camera is the effortless way to record any construction project. Set it and forget it. Create a time lapse video recorded at the rate you choose and played back at the speed you select when the project is complete.

RESERVOIR CONSTRUCTION
RPU – RESERVOIR CONSTRUCTION
by BanksPhotos
Demolition and construction of RPU’s 4th Street SW water reservoir from June through November 2013. This video represents one photo taken every 15 minutes with nights and weekends removed.

The video has approximately 6,480 images out of about 18,000 total shot. Captured with the Brinno TLC200 f.2 (BCC100) time lapse camera.



Housing Construction
HOUSING CONSTRUCTION PROJECT
by ArizonaDOT
The ‪‎Brinno ‪‎BCC100 ‪Timelapse ‪‎Camera gives you easy set-up, long battery life (up to 78 days), a lens that allows you to capture footage in low-light and a 140 degree field of view allowing you to capture more of the panoramic construction site. Construction Projects made easy!



MCDONALD'S CONSTRUCTION
MCDONALD’S CONSTRUCTION TIME LAPSE
by BanksPhotos
What sets this extensive video apart from traditionally edited time lapse videos was the minimal expense to secure Brinno BCC100 camera to the top of the job site trailer and interior shots were captured with a second Brinno TLC200Pro. Having the Brinno Cameras available was a bonus because a compelling time lapse video could easily be made for a fraction of the cost of traditional methods.’” Said by Josh Banks, Brinno authorized service provider. Courtesy of BanksPhotos



PEGULA ICE ARENA
PEGULA ICE ARENA – ICE FLOOR SLAB POUR TIME LAPSE
By Mortenson Construction
The concrete pour for the ice floor is a significant project milestone. “The challenges include: a continuous pour (with no construction joints), a very flat and level finish, and no breaks or leaks in the refrigerant piping,” said Steve Laurila, Senior Project Manager at Mortenson Construction. Learn more about this project milestone on www.mortenson.com
SOLAR PV AND WIND TURBINE
SOLAR PV AND WIND TURBINE INSTALLATIONS
by Genfit
Brinno Construction camera is also recommended by the Genefit. Check out Genefit’s Solar PV and Wind Turbine installations on this wonderful time-lapse video. Courtesy of Genefit.
Building a Backyard Retreat
BUILDING A BACKYARD RETREAT
by Klapprodt Pools
Do sub trades involved in remodeling, like painters, carpenters, flooring specialists need to worry about recording their work? Only if they want proof that they do what they have contracted to do, on the date promised. BCC100 gives visual proof of how you did the job, and even time and date stamps it. Any questions as to the work done are answered with a short video and the next client can see what type of work he can expect. Courtesy of Klapprodt Pools

Construction Time Lapse Video 1,2,3!

3 steps to create construction time lapse video.

Features

Worker friendly, Easy to set up!

No Professional photographer is needed to setup and operate or relocate the construction camera.
Any worker will be able to get the job done.

Amazing battery life

World record long term, battery operated construction camera,
with an outstanding 4 + months of battery life

140° Super wide angle view

The 140 degree field of view allows you to capture more of the panoramic construction site equally and simply.

f1.2 Aspherical glass lens

The f1.2 extra low light lens allows you to capture in low light, and see the details often lost in the dark.
You will never miss any on site activities.

Dust-proof, weather resistant housing

Yes, we know most construction site are outdoors; and in order to let you capture your entire construction project in any weather, we provide a weather resistant housing to protect your construction camera.

bcc100-certified-service-provider

Brinno Certified Service Provider

We recognize the value in building successful relationships with an extended network of Time-Lapse Photography/Video technology for utilizing Brinno products; we are continually expanding our partner portfolio. The following companies have taken the next step with Time-Lapse Cameras by completing a Time-Lapse photography/video with additional Brinno Security Products training and certification course. These companies are Brinno authorized service providers and sharing our commitment to best in class customer service and support.

SPECIFICATION

Specification

Brinno ships the exact product shown in the picture, however, colors and photos shown may vary from actual product colors due to computer monitor display settings. Therefore the you see here may be different then the actual product shipped.

CAMERA
Model BCC100
LCD Screen 1.44″ TFT LCD
Rotate Lens 120°
Waterproof IP X4 (In use with Weather Resistant Housing (ATH110))
CAPTURE MODE
Time Lapse Various time interval
Stop Motion Optional,(In use with Shutter Line (ATS110))
OPTICS LENS
Aperture f1.2
Lens type Aspherical Lens (glass lens)
Field of View 140° (480P)
112° (720P)
Focal Length 18 mm (35mm equivalent)
Focus Distance 30 cm (Minimum)
RECORDING
Time Lapse Video Format: AVI
Resolution: 1280x 720, 640x 480
Still Image Format: JPEG (only for using Shutter Line)
Resolution: 1280x 720, 640x 480
Memory Storage SD Card (Supported up to 32 GB)
TIME INTERVAL
ASAP Captures 1~ 4 photos per second
Custom From 1 second to 24 hours
POWER
Power source Battery: 4 AA Batteries
DC IN: 5V (Micro USB connector)
Battery Life Captures 270,000 photos at ASAP time interval,
DIMENSION
Size (DxWxH) 64x 46x 106 mm
Weight 120 g (without batteries)
Color Green/ Black
Package Contents
BCC100 Package Contents
Time Lapse camera TLC200f1.2
Weather Resistant Housing (ATH110)
Camera Wall Mount (AWM100)
Rubber Strap


* SD card may or may not be included
, please read the package contents listing.



Battery Life
TIME INTERVAL
FRAMES CAPTURED
EST. BATTERY LIFE
ASAP
270,000
2.2 days
1 sec
245,000
2.8 days
5 sec
228,000
13 days
10 sec
197,800
23 days
20 sec
137,400
32 days
30 sec
105,200
36 days
1 min
61,800
43 days
5 min
14,300
50 days
10 min
9,180
64 days
30 min
3,700
78 days
1 Hr
1,800
4 Hr
460
24 Hr
78
Comparision

BCC100
BCC200
MODEL BCC100 BCC200
Viewfinder 1.44″ LCD 1.44″ LCD
Image sensor 1.3 MP 1.3 MP HDR
Resolution 1280 x 720 (16:9) 1280 x 720 (16:9)
Aperture f/1.2 f/2.0
Focal length (mm) 18 (35mm equivalent) 19 (35mm equivalent)
Field of view 140° (480P) 112° (720P)
112° (720P)
Aspherical lens
Interchangeable CS mount lens
HDR video
Scene setting
White balance setting
Micro USB output
Webcam function
Extension port
Time interval 0.5 sec, 1 sec-24 hrs 0.3 sec, 1 sec-24 hrs
Battery life 270,000 photos 240,000 photos
Storage media SD/SDHC card SD/SDHC card
Media included 4GB 4GB
Maximum storage capacity 32GB 32GB
Video format AVI AVI
Weather resistant IPX4 (With housing ATH110) IPX4 (With housing ATH120)
Stop Motion video
Still images (JPEG, 1280 x 720)
Batteries required
External power
Holder Camera Wall Mount (AWM100) Aerospace-grade Aluminum Alloy
